RB8016 crossed roller bearing specifications:

More RB crossed roller bearing models.

RB8016 crossed roller bearing features:

1. Integrated inner ring with separable outer ring, clearance can be adjusted.

2. Sustain radial, axial, and moment loads at the same time.

3. High running accuracy supplied with normal clearance, little clearance, or even under a pre-load.

4. Stable rotation, spacer retainer prevents rollers from skewing, thus eliminates friction between rollers, and avoid increasing of the rotation torque.

FAQ

1. How to lubricate crossed roller bearings?
Unless otherwise stated, all BRS made RB series crossed roller bearings are filled with the proper amount of complex lithium grease before delivery. So users can directly put bearings into the application after receiving goods. Then after 1~6 months operation, bearings should be added with proper grease based on working conditions.

2. What is the warranty of this RB8016 crossed roller ing bearings?
BRS provide one year warranty for all crossed roller bearings that operating under common working conditions. We have excellent after-sale service to help users during the installation and application of bearings.

RB8016 cross roller ring bearing installation instructions

Cautions: For crossed roller bearings with split outer ring, when the rigidity of the mounting parts is not sufficient, stress concentration will occur at the contact area between the rollers and raceways, and the bearing performance will be deteriorated significantly.

Therefore, it is necessary to carefully examine the rigidity of housing and the strength of fixing bolts when a large moment will be applied.

1. Before installation, please clean bearing bracket, shaft, or other components, make sure there is no burrs or rough edge.
2. Fix the inner and outer rings in the axial direction by using fixing plates, etc.
3. Slightly loosen the fixing bolts of bearings outer ring during mounting.
